4 in 1 Engine Driven Welder And Plasma Cutting And AC Generator And Air Compression

About this item(SC200BF-2)4-in-1 Inverter engine driven stick welder&AC generator&air compression&Plasma Cutting,Solve outdoor welding and cutting problems.Generator: 7500 peak watts, 7000 running watts; comes with keychain, electric and recoil start; 20L fuel tank with fuel gauge, running time up to 6.5 hours. Rated speed (RPM) 3600. THD: Less than or equal to 3%Air compression:Oil free direct air compressor,20L air compression tank,Pressure range0.6-0.8Mpa; Flow 100L/min.Welder: 150A rated output current, welding current Range 50-200A; electrode range 1.6-4mm.Cutting: 10-40A output cutting current range,cutter plate thickness range1-10mm.The generator features 1 standard household AC socket. Powered by a  420cc four-stroke engine, it has an automatic low oil shut-off function and a 3-in-1 digital meter,plug and play.The welding module adopts IGBT inverter power system, suitable for mild steel, cast iron, stainless steel and hard surfaces.Simultaneous welding and electricity use,suitable for various occasions requiring welding, such as manufacturing and maintenance, emergency repairs, road maintenance, construction, etc.Accessories include keychain, oil funnel, tool kit and user manual. All CAMEO portable hair welders are functionally tested at the factory and may contain minimal residual oil and/or fuel odor; meet EPA, EU V, CE standards; provide 1 year limited service, labor and parts warranty.Applicable Industries:Hotels, Garment Shops, Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Restaurant, Home Use, Retail, Construction works , Energy & Mining, Food & Beverage Shops, Advertising Company.

Cyflwyniad Cynnyrch

xin-41-1

 About this item(SC200BF-2)
4-in-1 Inverter engine driven stick welder&AC generator&air compression&Plasma Cutting,Solve outdoor welding and cutting problems.
75007000 running watts; comes with keychain, electric and recoil start; 20L fuel tank with fuel gauge, running time up to 6.5 hours. Rated speed (RPM) 3600. THD: Less than or equal to 3%
Air compression:Oil free direct air compressor,20L air compression tank,Pressure range0.6-0.8Mpa; Flow 100L/min.
Welder: 150A rated output current, welding current Range 50-200A; electrode range 1.6-4mm.
Cutting: 10-40A output cutting current range,cutter plate thickness range1-10mm.
The generator features 1 standard household AC socket. Powered by a 420cc four-stroke engine, it has an automatic low oil shut-off function and a 3-in-1 digital meter,plug and play.



All CAMEO portable hair welders are functionally tested at the factory and may contain minimal residual oil and/or fuel odor; meet EPA, EU V, CE standards; provide 1 year limited service, labor and parts warranty.

xin-41-2



31-4





multi functional product 3 in 1 multi functional product 4 in 1

SC200BS-SC200BF

product-1-1
SC200BS SCD200A SC200BF-1 SC200BF-2
60% 35% 60% 60%
DC 75V DC 75V DC 75V DC 75V
130/180 40A-160A 50A-200A 50A-160A
22-28V 22-28V 22-28V 22-28V
1.6-4.0mm 2.5-3.2 1.6-4.0mm 1.6-4.0mm
160A/27.2V 21.6-26.4V 180A/27.2V 150A/26V
4.5kW 6kW 5kW 7kW
5kW 6.5kW 5.5kW 7.5KW
50Hz/60Hz 50Hz/60Hz 50Hz/60Hz 50Hz/60Hz
17L / 2*10L /
100L/min / 100L/min /
0.6-0.8Mpa / 0.6-0.8Mpa /
SC420/CH440 SV320BA SC420/CH440 SC420/CH440
8.2kw/3600rpm 3600rpm 14HP/3600rpm 14HP/3600rpm
420cc/429cc 322cc 420cc/429cc 420cc/429cc
Recoil/E-start E-start Recoil/E-start Recoil/E-start
30 12.5 30 30
IP21S IP21S IP21S IP21S
860*600*800 770*500*525 860*615*930 800*620*990
120 130 160 158
/ 10-40 / 10-40
/ 1-10 / 1-10
/ / LED 4X100 /
/ / 3.5m /





---9



---10 -

---8

---11
